Established in 1996, DongGuang RuiChang Carton Machinery Manufacture Co.,LTD is a professional manufacturer of flexo print slot die cut machine. We are located in DongGuang County which is famous for packing hometown with convenient transportation to TianJin sea port. Our print slot die cut machine comply with international quality standards and are greatly accepted by customer from domestic and aboard market.
We have over 50 employees, 2 engineers for technical upgrade,1 engineer for machine design ,70% of them worked for RuiChang Machine over 10 years.
If you are interested in any of our machine, please feel free to contact us for further information, we are looking forward to forming successful business relations with clients around the world in the near future.
Looking forward to your reply!
http://www.rczxjx.com.cn
Lucas
Mobile/Whats app:+8615100759783 Wechat: w229381567
Technical data
|
Type |
Unit |
ZYKM1626 |
|
Design speed |
Pcs/min |
150 |
|
Working speed |
Pcs/min |
100-120 |
|
Max paper coverage |
mm |
1600*2600 |
|
Effective printing area |
mm |
1600*2400 |
|
Min finish size |
mm |
450*600 |
|
cardboard thickness |
mm |
2.5-12 |
|
Wall thickness |
mm |
50mm |
|
Print precision |
mm |
≤±0.4 |
|
Slot /cutting precision |
mm |
≤±1 |
Machine details
Feeding unit
Individual feeder system ,it is very steady when machine running ,and it is easier to adjust.
Touch screen available ,size input by screen or buttons based on operator needs.
Four lines rubber wheels for feeding, it is fit for big size cardboard.
Brush device is available ,which can clean the cardboard before printing.
Four rollers for feeding, two of them is rubber material which can keep the flute in good shape, not destroyed .
Delta inventor and PLC ,touch screen operation .
Schneider contactor/ electric
Main bearing use NSK brand.
wall thickness is 50mm
working speed: 120 sheets/minute
it adopts lead edge type feeding with 7.5 kw adsorption motor.
40Cr material /grinding technology for gears
Printing unit
There is plating hung bar, it is easy to install the printing plate.
Two layer machine covers ,it is more easier to adjust the distances between rollers.
Rubber roller made in JiZhou which is durable.
Ink rollers made in HaiLi which is the best quality
Ink box is made of stainless steel ,auti-corrosion and longer service life.
Electrical phase made in ZheJiang.
PLC plate and button adjusted on the side.
Ink automatic cycle.LPI ranged from 200 to 300 as customer required.
All gear is grinding technology and 40Cr material.
Main bearing use NSK brand.
Rollers adopt dynamic balance process which can improve the precision of machine.
Slotter unit
Automatic slotting unit
All gears is grinding technology and 40 Cr material
Creasing line and slotting blade position move together ,it can prolong the knife service life
Die cutter unit
Die cutting roller and rubber roller adopt dynamic balance technical
Anvil cover is made in TaiWan,durable and longer service life.
All gear is fine grinding technology and 40Cr material.
Main bearing use NSK brand.
Rollers adopt dynamic balance process which can improve the precision of machine.
Stacker unit
Stripper device is used for clearing the waste of sheet margin ,then transfer to stacker device,which collect the carton in pile based on pre-set in advance.
